Product introduction:

The pumps are suitable for use in applications such as for draining flooded areas such as cellars,underground car parks,are washed,for emptying cesspools.the pumps distinguish themselves for their reliability which can be best appreciated under automatic operating conditions in fixed installations.

Component Construction :

Pump body : Cast Iron with special anti-rust treatment

Motor housing : AISI304

Impeller：Cast iron

Motor shaft : Carbon Steel (304ss if request)

Mechanical seal : Ceramic / Graphite

Operating Condition:

Liquid Temperature up to 60 ℃

Ambient Temperature up to 40 ℃

5m maximum immersion depth

Motor :

Single Phase 220V /50Hz ,110V /60Hz if request

Insulation Class B

Production :IP44,IP54 if request

With Thermal Protector

Continuous Work S1
