Application:

For water supply from wells or reservoirs.

For domestic civil and industrial applications .

For garden use and irrigation .

Component Construction :

Outlet:  Brass

Impeller :  Brass

Motor shaft:   AISI304SS

Top chock  ： Cast-CU/Cast Iron

Seal lubricant oil : 10# white oil

Mechanical seal : graphite-ceramic

Operating Condition:

Maximum fluid temperature up to +35 ℃

Maximum sand content :0.25%

Maximum immersion: 120m

Minimum well diameter :  4 “

Motor and pump :

Rewindable motor

Single Phase :180V-240V /50Hz

Equip with start -up control box
